- 5 Mic & 2 Aux Inputs.
- 60W+60W power output.
- Connecting two groups of speakers, preamplifier output, bass, and treble controls, zone On/Off facility, and AC/DC operation have been provided.
- TZA-1200 is suitable for small-sized installations such as in places of worship where both external and internal speakers are required to be connected with different sound level settings.
| Power Output | 90W + 90W Max., 60W + 60W RMS at 10% THD, 55W + 55W RMS at 5% THD, 50W + 50W RMS at 2% THD |
| Output Regulation | ≤ 2 dB, no load to full load at 1kHz |
| Input Channels | 5 × Mic 0.6mV/4.7kΩ, 1 × Aux 100mV/470 kΩ, 1 × Aux 200mV/250kΩ (RCA Jack) |
| Frequency Response | 70-15,000Hz ±3dB |
| Signal-to-Noise Ratio | 60dB |
| Tone Controls | Bass: -10dB at 100Hz, Treble: -10dB at 10kHz |
| Outputs | Preamp 200mV/600Ω |
| Speaker Outputs | 4Ω, 8Ω, 16Ω & 100V for each zone |
| Power Supply | AC: 220-240V 50/60Hz DC: 12V (12V Car Battery) |
| Power Consumption | AC: 250VA DC: 5A |
| Dimensions | W400 × H130 × D290 mm |
| Weight | 10.1kg |
